Metal Mesh Atomizer 113KHz 18µm 600 mm/Hr

SMMOD20F113H18 - 2 Pc/Set
Manufacturer part number: SMMOD20F113H18
Availability: Out of stock
/2 Pcs Set
Condition: New

Part Number: SMMOD20F113H18

Metal mesh oscillator Transducer for mist generation. Liquids can also be feed to this transducer by capillarity. An important application of this transducer is medicine and drug delivery by Inhalation aerosol.

If a 20mm Silicone gasket is needed you can find it HERE

Piezo Material: SM412
Dimensions: 20mm Diameter ± 0.2
Resonant frequency fr: 113 KHz±7KHz
Resonant impedance Zm: ≤150 Ω
Static capacitance Cs: 6.5nF±1.5nF@1kHz
Maximum Voltage Input: 60 Vp-p
Mist Production: 600 cc/Hr *
Droplet size is  18um.
Number of Holes:  395±10%
Metal mesh Material: SUS304
Wire Leads: 45mm, UL 1571, 30#  (The surface with the soldered black wire should face the liquid)
Working temperatureļ¼š-10°C~40°C
Storage temperatureļ¼š-30°C~80°C
Test Condition: 25±3 °C 40~70% R.H.
Cs => LCR meter at 1KHz 1Vrms

Applications: Nebulizer transducer, Aromatherapy mist generation transducer, Mist generation transducer for Hydroponic chamber, Humidifier transducer, Inhalation and equipment disinfections, Humidification in refrigerated food displays and storage, living environment and air conditioning plants, Hydroponics cultures, Humidification in industrial process, control for lubrication, coating, Facial beautification, Transducer for drug and medicine deliver by mist, Inhalation aerosol, ICP instrument and others.

*Typical values in our laboratory testing results, these values will depend on drive circuit and fan speed.
   Measurements were done with the atomizer floating on the surface without water covering the top side of the transducer.

Specification of products can change without notice.
